It is New Tool Tuesday! - New Tools Other Tilers Have Bought Recently

[Concrete guy]

Im new to the polishing game but im putting an order in with you imminently so im going to order a polishing disc.. I mainly work with porcelain so if you could direct me on what I should get to have a play around with...

I'll run through some of the more common applications in tiling:-

Electroplated diamond hand pads #50 to #400 grit. These are ideal for tidying up edges and envelope cuts on individual tiles. You wouldn't want to be doing much quantity with these, they are a handy tool to have in the kit.

Silicon Carbide discs:- The reality is you can polish pretty much anything with these, they are probably the most appropriate product for a tiler that does a bit of polishing every now and again.

The very low grits #40,#60,#80 you're grinding. #120-#320 is honing. #400 upwards is varying degrees of polish. #1200 is very fine, often used in glazing to polish glass.

Silicon carbide grits do not relate to diamond grits. Diamond pads generally range from #30 to #6000 whereas the same range is covered in SiC discs in #40 to #1200. (#1200 SiC is about #6000 diamond).

The main advantage of diamond pads (the round one you use on a polisher) is longevity, they last far longer so are more economical when doing lots of polishing, particularly wet polishing.

Dry diamond pads are simply less messy (more dust, less water) cost more than wet pads, generally don't last as long but easier to use on site. You don't have to dress like a fishmonger to use them.

Any specific questions just ask.



[Waluigi]

Be good if you add some feedback on them when you've used them, with images too please.
Started staying clear of the M14 bits, they don’t seem to be cutting clean enough unless you buy high end pieces.
I’ve moved back too the cheapest vacuum braised bits cos they’re leaving cleaner cuts

As I said before, you’re absolutely right about these holes not being as clean as the cheaper water cooled bits. That’s fine for me though as very few cuts I produce are ever on display. I still have a load of the cheaper bits if they are on display but for now, the vacuum brazed bits cut through dry in 20 seconds for each hole in Porcelain.

You can see the chipping though.



[Italy]

As I said before, you’re absolutely right about these holes not being as clean as the cheaper water cooled bits. That’s fine for me though as very few cuts I produce are ever on display. I still have a load of the cheaper bits if they are on display but for now, the vacuum brazed bits cut through dry in 20 seconds for each hole in Porcelain.

You can see the chipping though.

View attachment 100516
View attachment 100517

what bit are you using?



[Dumbo]

As I said before, you’re absolutely right about these holes not being as clean as the cheaper water cooled bits. That’s fine for me though as very few cuts I produce are ever on display. I still have a load of the cheaper bits if they are on display but for now, the vacuum brazed bits cut through dry in 20 seconds for each hole in Porcelain.

You can see the chipping though.

View attachment 100516
View attachment 100517

You need one those hole dressing stones like @antonio has got . In fact I need one to



[Waluigi]

what bit are you using?

It’s a few posts up- vacuum brazed Chinese



[Italy]

It’s a few posts up- vacuum brazed Chinese

a picture of the bit thanks....
I can no longer remember the trend line 🙁



[Waluigi]

https://www.tilersforums.com/attachments/f393473d-52d3-4ac0-936d-a9016a854219-jpeg.100455/



[Italy]

https://www.tilersforums.com/attachments/f393473d-52d3-4ac0-936d-a9016a854219-jpeg.100455/

thanks



[Waluigi]

You need one those hole dressing stones like @antonio has got . In fact I need one to

Just clicked what you meant. Yeah I know exactly what you mean.

I’m not too fussed about a few little chips on a hole. None will be seen once I put my metal shrouds on.



[Italy]

new graphics...
