Sigma Kera Lift, large format tile lifting system.

[Old Mod]

Is the system used to lift large sheets of glass?

Not that I know of Sharon, large sheets of glass are normally moved with something like this,
I wonder where Raimondi took their inspiration from?



[Old Mod]

With 6 cups is the expensive one...What about the another one with 2 vacuum cups is any god?

In my image Ed?
This one?


That is one side of the 1m x 1m frame, and it works well I think.
You can purchase single arm, but it is larger and extends. This is fixed at 1m



[Flintstone]

Well you'll be pleased to know that they are coming out of Italian factories now at 5m!

Is a joint really so offensive ?



[Italy]

Well you'll be pleased to know that they are coming out of Italian factories now at 5m!

Who does them?



[Old Mod]

Is a joint really so offensive ?

If you're an average guy, probably not.
If you're old bill on the other hand, probably!



[Simons70]

In my image Ed?
This one?
View attachment 91236

That is one side of the 1m x 1m frame, and it works well I think.
You can purchase single arm, but it is larger and extends. This is fixed at 1m

No,this one I think is part of the system.Sigma have more systems but for 3m+ have 2 systems as far I see,one with 2 vacuum and the rest is normal cups,cost around 800£ and the another one have 6 vacuum and cost around 1400£.
I want to know if the chip one is any god because 1400£ is really expensive.I vacuum separately cost anyway more then 200£...



[Old Mod]

No,this one I think is part of the system.Sigma have more systems but for 3m+ have 2 systems as far I see,one with 2 vacuum and the rest is normal cups,cost around 800£ .

From what I saw yeasterday Ed, the 4 ordinary cups with extra 2 vacuum cups is enough. They work with textured tiles too!
So if I wanted larger system it would be one of these two. They also have extra safety hooks if cup fails.






We used system yesterday with ordinary cups only, it worked perfectly, tile and adhesive was 42kgs plus 16kg for frame.



[Blunt Tool]

From what I saw yeasterday Ed, the 4 ordinary cups with extra 2 vacuum cups is enough. They work with textured tiles too!
So if I wanted larger system it would be one of these two. They also have extra safety hooks if cup fails.
View attachment 91238

View attachment 91239

View attachment 91237

We used system yesterday with ordinary cups only, it worked perfectly, tile and adhesive was 42kgs plus 16kg for frame.

Ordered



[One Day]

Who does them?

Not sure Antonio, but my local tile shop Roccia claimed so. 5m x 1.6 x 6mm!



[Old Mod]

Not sure Antonio, but my local tile shop Roccia claimed so. 5m x 1.6 x 6mm!

I was told recently that a new breed of tile is about to hit the market, they have a high metal content, yes on purpose.
Reason being is that they are being aimed at the cladding market.
Idea being that magnetic strips are mechanically fixed to the building and the tiles are literally stuck to the magnets. Good luck cutting them!



[One Day]

I was told recently that a new breed of tile is about to hit the market, they have a high metal content, yes on purpose.
Reason being is that they are being aimed at the cladding market.
Idea being that magnetic strips are mechanically fixed to the building and the tiles are literally stuck to the magnets. Good luck cutting them!

And some are going to get sold into retail, or spec'd by enthusiastic interior designers...
Time we all started covering ourselves in our terms and conditions, on the handling and cutting side of things I think...



[Old Mod]

on the handling and cutting side of things I think...

Was talking to Stuart, (Stu Lilley) the other day in fact, and he was saying that he knows of some tiles independently tested and they were so far over grade 6 they were off the scale, and even actually contained steel. From Asian countries I might add.
So it's not a wonder that cutting porcelain is getting harder everyday.



[MTiler]

Not that I know of Sharon, large sheets of glass are normally moved with something like this,
I wonder where Raimondi took their inspiration from?

View attachment 91235

Same difference



[nicknick81]

Alternatively you could always forget about the fancy expensive gadgets and just hire an extra pair of hands for the day. Large format tiles need to be handled with care ideally by 2 installers as per this youtube vid



[Chalker]

Alternatively you could always forget about the fancy expensive gadgets and just hire an extra pair of hands for the day. Large format tiles need to be handled with care ideally by 2 installers as per this youtube vid

Nice to mr Chumley Warner ( posh guy) still has a job narrating
